THE NAME:

10000KG Parallel Mount Motorized Electric Linear Actuator

Model: LAP10000
Place of Origin: Made In China
Brand Name: JACTON
Download:
Description:
Industrial Heavy Duty Motor Drives Linear Actuator: An integrated compact combination of ordinary tooth screw/ball screw/planetary ball screw, reducer and motor.  Linear actuators are a type of actuator that convert rotational motion in motors into linear or straight push/pull movements. Linear actuators are ideal for all types of applications where tilting, lifting, pulling or pushing with pounds of force are required. Electric linear actuators are often the preferred solution when you need simple, safe and clean movement with accurate precision and smooth motion control. Wide Use - Our linear actuator with durable stroke ideal for Various light industrial applications massage sofa, recliner, TV lifter, lifting table, hood, fan blades, cabinets, window opener, robotics, home automation, etc.

High Force 10000KG Parallel Mount Motorized Electric Linear Actuator Replacement for Hydraulic Actuators and Pneumatic Cylinders. 10000KG Parallel Mount Motorized Electric Linear Actuator features include heavy load capacity, high linear speed, long service life, low noise system, no oil leaks, contamination or fire risk, accurate and repeatable positioning using simplified system, easy synchronization, easy installation, no pipework, powerpack and valves, choice of end fittings like clevis, threaded end, top plate, trunnion mounting (with or without feet), proximity switches, guided ram (guiding the load side loads on the actuator ram should be avoided by ensuring that the load is guided), and bellows boots. 10000KG Parallel Mount Motorized Electric Linear Actuator are used for opening and closing, tilting and pivoting, lifting and lowering and positioning. For example gates, dampers, oven and processing tank doors, antennas, orthopedic tables and other medical equipment, ergonomic furniture, and agricultural equipment, scissor platforms, lifting platforms, robotics, continuous paint pumps, medical beds, coiling machines, tundish cars, continuous operation process lines. Custom designs are also available for special applications.


10000KG Parallel Mount Motorized Electric Linear Actuator Technical Details & Drawings



Trunnion Mounting Feet Drawings



10000KG Parallel Mount Motorized Electric Linear Actuator Internal Structure

1. Motor2. Gear (1st)3. Gearbox4. Gear (2nd)
5. Gear (3rd)6. Handwheel7. Gear (4th)8. ACME screw
9. Base10. Pull rod11. Safety switches12. Disc spring
13. Screw nut14. Guide rail 15. Guide bush16. Cylinder, 17. Rod end fork

10000KG Parallel Mount Motorized Electric Linear Actuators are application in gates, dampers, oven and processing tank doors, antennas, orthopedic tables and other medical equipment, ergonomic furniture, and agricultural equipment, scissor lifts, scissor platforms, lifting platforms, robotics, continuous paint pumps, medical beds, coiling machines, tundish cars, continuous operation process lines opening and closing, tilting and pivoting, lifting and lowering, and positioning etc. Custom designs linear cylinders are also available for your special applications.
