THE NAME:

4000KG Heavy Duty Electric Linear Actuators Parallel Mount

Model: LAP4000
Place of Origin: Made In China
Brand Name: JACTON
Download:
Description:
Linear Actuators - Rod Style: Acme or ball screw drive available with motor, drive, controller, and power supply. Configure a complete Electric Linear Actuators system with AC or DC motors and a wide variety of options such as limit switches, gearboxes, and sensors. Configurations include parallel or inline with motor mounts and single or double gear reductions. Product lines include Programmable Linear Actuators (high accuracy and precision), Electric Cylinders (heavy duty durability), and Commercial Series Linear Actuators.

4000KG Heavy Duty Electric Linear Actuators Parallel Mount Vs. Hydraulic Cylinders Vs. Pneumatic Cylinders. 4000KG Heavy Duty Electric Linear Actuators Parallel Mount can not only match the load capacity of hydraulic cylinders and exceed the load capacity of conventional electric linear actuators. Main application in coiling machines, decoiling machines, continuous operation process lines, tundish cars, scissor lifts, lifting platforms, robotics, continuous paint pumps, medical beds, gates, dampers, oven and processing tank doors, antennas, and agricultural equipment. 4000KG Heavy Duty Electric Linear Actuators Parallel Mount are used for opening and closing, tilting and pivoting, lifting and lowering and positioning. For example gates, dampers, oven and processing tank doors, antennas, orthopedic tables and other medical equipment, ergonomic furniture, and agricultural equipment, scissor platforms, lifting platforms, robotics, continuous paint pumps, medical beds, coiling machines, tundish cars, continuous operation process lines. Custom designs are also available for special applications.


4000KG Heavy Duty Electric Linear Actuators Parallel Mount Technical Details & Drawings



Trunnion Mounting Feet Drawings



4000KG Heavy Duty Electric Linear Actuators Parallel Mount Internal Structure

1. Motor2. Gear (1st)3. Gearbox4. Gear (2nd)
5. Gear (3rd)6. Handwheel7. Gear (4th)8. ACME screw
9. Base10. Pull rod11. Safety switches12. Disc spring
13. Screw nut14. Guide rail 15. Guide bush16. Cylinder, 17. Rod end fork

4000KG Heavy Duty Electric Linear Actuators Parallel Mount are application in gates, dampers, oven and processing tank doors, antennas, orthopedic tables and other medical equipment, ergonomic furniture, and agricultural equipment, scissor lifts, scissor platforms, lifting platforms, robotics, continuous paint pumps, medical beds, coiling machines, tundish cars, continuous operation process lines opening and closing, tilting and pivoting, lifting and lowering, and positioning etc. Custom designs linear cylinders are also available for your special applications.
