THE NAME:

JTW-35T Machine Screw Jack

Model: JTW-35T-Machinescrewjack-Tr100x20
Categories: JTW Machine Screw Jack »
Place of Origin: Made In China
Brand Name: JACTON
Download:
Description:
JTW-35T Machine Screw Jack Pictures


JTW-35T Machine Screw Jack Features
1. Maximum load capacity 35 ton, maximum torque 464 Nm.
2. Lift screw diameter 100 mm, pitch 20 mm. Gearbox sizes 435x280x240mm. Center height 115mm, center distance 120mm. Worm shaft diameter 38mm.
3. 32:3, 32:1 gear ratios
4. Translating screw, rotating screw with aluminum bronze traveling nut, non-rotation keyed screw configurations in upright or inverted mounting orientation.
5. Precisely positioning, self-locking acme screw which supports the loads and hold position with no need to employ brake mechanism or other locking systems.
6. Manual machine screw jack by hand wheel or hand crank, electrical drive machine screw jack by electric motor or gearmotor driven, or both.
7. 3-phase or single phase motor driven with 1500 rpm input, standard lifting speed 2813 mm/min and 938 mm/min.
8. Top plate (I), clevis end (II), plain end(III) and threaded end (IV) are available. Custom made spherical hinge, forked head.
9. Individually or multiple jtw-35t machine screw jack lift system arrangements are available.

JTW-35T Machine Screw Jack Specifications


JTW-35T Machine Screw Jack Dimensional Drawing
