Eight Lifting Points Systems

Complete eight points lifting systems with geared motors and couplings available. Multiple screw jacks can be combined into a lifting system. Powered by a geared motor, the jacks are connected often in an "H" configuration by couplings and bevel gears. We can supply complete lifting systems, talk to our Engineers.


Eight Lifting Points Systems Configurations
* H - configuration: 8pcs worm gear screw jacks+21pcs couplings+3pcs miter gearboxes+1pc motor/reducer (electrically) or 1pc hand wheel (manually).
* HH - configuration: 8pcs worm gear screw jacks+29pcs couplings+7pcs miter gearboxes+1pc motor/reducer (electrically) or 1pc hand wheel (manually).
Note: When connecting shafts length is exceed maximum distance of between supports, Pillow blocks are required.
