JDT32 Mechanical Linear Actuators Pictures

JDT32 Mechanical Linear Actuators Specifications
Linear Actuators features: A compact combination of a common acme screw/ball screw and a reducer and motor. The unique price/performance ratio and unparalleled advantages provide engineers with vast design space. Self-locking, Mostly have an absolute self-locking function, which increases the safety of equipment operation. Precision positioning, up to 0.1mm. Precise control, Encoder, transformer, potentiometer are available. Closed-loop precise positioning through inverter, servo controller, PLC control. Synchronization, Multiple linkages are synchronized. Stroke up to 2000mm. Simple maintenance, low noise, and normal operation in high, low temperature, anti-corrosion, explosion-proof environment.

JDT32 Mechanical Linear Actuators Without Limit Switches Dimensional Drawing
About 2D Autocad dwg, dxf assembly drawings, and 3D stp, step, model, igs, prt or catpart assembly drawings, please contact Jacton Industry directly.
JDT32 Mechanical Linear Actuators With Proximity Limit Switches Dimensional Drawing
JDT32 Mechanical Linear Actuators With Motor Flanges Dimensional Drawing
Dimensions are subject to change without notice.
