THE NAME:

90 degree right angle bevel gear reducer iec input flange 1 1 ratio

Model: 90 degree right angle bevel gear reducer
Place of Origin: Made In China
Brand Name: JACTON
Download:
Description:
cubic 90 degree right angle bevel gear reducer iec input flange 1:1 ratio pictures and models as below:

JTP90 Bevel Gears
1.gear ratios 1:1, 1.5:1, 2:1, 3:1, 4:1, 5:1
2.cubic,6 mount positions
3.solid shaft&hollow shaft
4.2 way,3 way,4 way shafts
5.input power max. 6Kw
6.drive torque max. 43.3Nm
7.drive shaft diameter 18mm
JTP110 Bevel Gears
1.gear ratios 1:1, 1.5:1, 2:1, 3:1, 4:1, 5:1
2.cubic,6 mount positions
3.solid shaft&hollow shaft
4.2 way,3 way,4 way shafts
5.input power max. 11Kw
6.drive torque max. 78.3Nm
7.drive shaft diameter 22mm
JTP140 Bevel Gears
1.gear ratios 1:1, 1.5:1, 2:1, 3:1, 4:1, 5:1
2.cubic,6 mount positions
3.solid shaft&hollow shaft
4.2 way,3 way,4 way shafts
5.input power max. 23.9Kw
6.drive torque max. 170Nm
7.drive shaft diameter 32mm
JTP170 Bevel Gears
1.gear ratios 1:1, 1.5:1, 2:1, 3:1, 4:1, 5:1
2.cubic,6 mount positions
3.solid shaft&hollow shaft
4.2 way,3 way,4 way shafts
5.input power max. 39.2Kw
6.drive torque max. 290Nm
7.drive shaft diameter 40mm
JTP210 Bevel Gears
1.gear ratios 1:1, 1.5:1, 2:1, 3:1, 4:1, 5:1
2.cubic,6 mount positions
3.solid shaft&hollow shaft
4.2 way,3 way,4 way shafts
5.input power max. 67.5Kw
6.drive torque max. 520Nm
7.drive shaft diameter 45mm
JTP240 Bevel Gears
1.gear ratios 1:1, 1.5:1, 2:1, 3:1, 4:1, 5:1
2.cubic,6 mount positions
3.solid shaft&hollow shaft
4.2 way,3 way,4 way shafts
5.input power max. 90.5Kw
6.drive torque max. 694Nm
7.drive shaft diameter 55mm
JTP280 Bevel Gears
1.gear ratios 1:1, 1.5:1, 2:1, 3:1, 4:1, 5:1
2.cubic,6 mount positions
3.solid shaft&hollow shaft
4.2 way,3 way,4 way shafts
5.input power max. 156Kw
6.drive torque max. 1199Nm
7.drive shaft diameter 60mm


t type 90 degree right angle bevel gear reducer iec input flange 1:1 ratio pictures and models as below:


JT15 Bevel Gears
1.spiral teeth miter gears
2.90 degree angle assembly
3.miter gear ratio 1:1, 2:1
4.2 way,3 way,4 way shafts
5.input power max.1.79Kw
6.drive torque max. 28Nm
7.drive shaft diameter 15mm
JT19 Bevel Gears
1.spiral teeth miter gears
2.90 degree angle assembly
3.miter gear ratio 1:1, 2:1
4.2 way,3 way,4 way shafts
5.input power max. 4.94Kw
6.drive torque max. 48.5Nm
7.drive shaft diameter 19mm
JT25 Bevel Gears
1.spiral teeth miter gears
2.90 degree angle assembly
3.gear ratios 1:1, 1.5:1, 2:1, 2.5:1, 3:1, 4:1, 5:1
4.2 way,3 way,4 way shafts
5.input power max. 14.9Kw
6.drive torque max. 132Nm
7.drive shaft diameter 25mm
JT32 Bevel Gears
1.spiral teeth miter gears
2.90 degree angle assembly
3.gear ratios 1:1, 1.5:1, 2:1, 2.5:1, 3:1, 4:1, 5:1
4.2 way,3 way,4 way shafts
5.input power max. 22Kw
6.drive torque max. 214Nm
7.drive shaft diameter 32mm
JT40 Bevel Gears
1.spiral teeth miter gears
2.90 degree angle assembly
3.gear ratios 1:1, 1.5:1, 2:1, 2.5:1, 3:1, 4:1, 5:1
4.2 way,3 way,4 way shafts
5.input power max. 45.6Kw
6.drive torque max. 361Nm
7.drive shaft diameter 40mm
JT45 Bevel Gears
1.spiral teeth miter gears
2.90 degree angle assembly
3.gear ratios 1:1, 1.5:1, 2:1, 2.5:1, 3:1, 4:1, 5:1
4.2 way,3 way,4 way shafts
5.input power max. 65.3Kw
6.drive torque max. 561Nm
7.drive shaft diameter 45mm
JT50 Bevel Gears
1.spiral teeth miter gears
2.90 degree angle assembly
3.gear ratios 1:1, 1.5:1, 2:1, 2.5:1, 3:1, 4:1, 5:1
4.2 way,3 way,4 way shafts
5.input power max. 96Kw
6.drive torque max. 919Nm
7.drive shaft diameter 50mm
JT60 Bevel Gears
1.spiral teeth miter gears
2.90 degree angle assembly
3.gear ratios 1:1, 2:1, 3:1, 4:1, 5:1
4.2 way,3 way,4 way shafts
5.input power max. 163Kw
6.drive torque max. 1940Nm
7.drive shaft diameter 60mm
JT72 Bevel Gears
1.spiral teeth miter gears
2.90 degree angle assembly
3.gear ratios 1:1, 2:1, 3:1, 4:1, 5:1
4.2 way,3 way,4 way shafts
5.input power max. 234Kw
6.drive torque max. 3205Nm
7.drive shaft diameter 72mm
JT85 Bevel Gears
1.spiral teeth miter gears
2.90 degree angle assembly
3.gear ratios 1:1, 2:1, 3:1, 4:1, 5:1
4.2 way,3 way,4 way shafts
5.input power max. 335Kw
6.drive torque max. 5713Nm
7.drive shaft diameter 85mm
