K37 KA37 KF37 KAF37 KAZ37 KAB37 KAT37 Helical-bevel Gearmotor Features
K37 KA37 KF37 KAF37 KAZ37 KAB37 KAT37 Helical-bevel Gearmotor input power 0.18kw, 0.25kw, 0.37kw, 0.55kw, 0.75kw, 1.1kw, 1.5kw, 2.2kw, 3kw, max. permissible torque up to 200Nm, transmission ratios from 5.36 to 106.38, available versions include Foot-mounted or flange-mounted, Solid or hollow shaft, B5 or B14 Flange-mounted, Hollow shaft with keyed connection, shrink disc, splined hollow shaft or Torque arm mounted.
K37 KA37 KF37 KAF37 KAZ37 KAB37 KAT37 Helical-bevel Gearmotor provide a high degree of efficiency of over 96% in both torque directions and at all input speeds. With performance designed to last–high-endurance gearing enables high-torque, wear-free operation. With our remarkably efficient helical-bevel gearmotors, you have energy-saving angular gear drives at your fingertips. As they also have a long maintenance-free service life, they can be used in every application with AC asynchronous motors, asynchronous and synchronous servomotors.
K37 KA37 KF37 KAF37 KAZ37 KAB37 KAT37 Helical-bevel Gearmotor Dimensions and Motor Power
K37 KA37 KF37 KAF37 KAZ37 KAB37 KAT37 Helical-bevel Gearmotor Selection GuidesK AF 37 Y 0.25 - 4P 24.99 M1 0 A CW
1 2 3 4 5 6 7 8 9 10
1. K: K Series Helical-bevel Gearmotor / Helical-bevel Gear Reducer
2. Structure Types:* No Marks K: Foot-mounted helical-bevel gearmotors with solid shaft.
* KA: Helical-bevel gearmotors with hollow shaft.
* KF: B5 Flange-mounted helical-bevel gearmotors with solid shaft.
* KAF: B5 Flange-mounted helical-bevel gearmotors with hollow shaft.
* KAB: Foot-mounted helical-bevel gearmotors with hollow shaft.
* KAZ: B14 Flange-mounted helical-bevel gearmotors with hollow shaft.
* KAT: Torque arm mounted helical-bevel gearmotors with hollow shaft.
3. Sizes: 37 (dimensions above)
4. Motor Code:* Y (Y2): Normal (Renew) 3-phase motors
* B: Explosion-proof motors
* Z: Direct-current DC motors
* YEJ: Brake motors
* D: Multi-speed motors
* YVP: Variable frequency motors
* YCT: Electromagnetic speed regulation motors
* R: Crane and metallurgy motors
* YVPJ: Variable frequency and brake motors
* G: Roller table motors
5. Motor power & Pole & 6. Transmission ratio: see below websites
0.18kw: http://www.screw-jack.com/018kw-helical-bevel-gearmotor-specifications.html
0.25kw: http://www.screw-jack.com/025kw-helical-bevel-gearmotor-specifications.html
0.37kw: http://www.screw-jack.com/037kw-helical-bevel-gearmotor-specifications.html
0.55kw: http://www.screw-jack.com/055kw-helical-bevel-gearmotor-specifications.html
0.75kw: http://www.screw-jack.com/075kw-helical-bevel-gearmotor-specifications.html
1.1kw: http://www.screw-jack.com/11kw-helical-bevel-gearmotor-specifications.html
1.5kw: http://www.screw-jack.com/15kw-helical-bevel-gearmotor-specifications.html
2.2kw: http://www.screw-jack.com/22kw-helical-bevel-gearmotor-specifications.html
3kw: http://www.screw-jack.com/3kw-helical-bevel-gearmotor-specifications.html
7. Mounting position: M1, M2, M3, M4, M5, M6 (see below picture)
8. Position of the motor thermal box: 0, 90, 180, 270 degrees (see below picture)
9. Position of output shaft, shrink disc or flange: A, B, or A+B
10. Rotation directions of output shaft: CW (clockwise) or CCW (counter clockwise)
