THE NAME:
solar tracking machine screw jack actuators
Model: solar tracking machine screw jack actuat
Categories: Screw jack for solar panel tracking system mechanism. »
Place of Origin: Made In China
Brand Name: JACTON
Download:
Description:
solar tracking machine screw jack actuators accurate positioning solar panel tracking system, which is the ideal solutions of solar panel tracking system, because solar tracking machine screw jack actuators is equipped with self-locking acme screw, protective pipe, bellows boot, limit switches, swivel plate, swivel mounting base, electric motor and gear reducer. solar tracking machine screw jack actuators solves the problem that solar panel tracking system must be highly rugged and can withstand wind force and weather,function reliably,maintenance free for many years,safety self locking and accurate positioning tracking movement. If solar tracking machine screw jack actuators with high accuracy ball screw, must be equipped with brake mechanism.
Tracking the movement of the sun will boost the efficiency and increase output from a given panel by up to 30%. Accurate, trouble-free positioning of the panels is the challenge. The system must be highly rugged and able to withstand wind and weather. It must function reliably and maintenance-free for many years. Thomson linear actuators and screw jacks offer affordable, custom-fitted solutions to these challenges.
Solar tracking requires actuation solutions which are stiff and will not back-drive in high wind conditions. All Thomson actuators and screw jacks can be equipped with a holding brake that eliminates back-driving.
Accurate tracking often requires some form of feedback. Most Thomson actuators and screw jack models can be equipped with encoders, resolvers or potentiometers to meet either analog or digital feedback requirements.
All Thomson actuators and screw jacks are available with adjustable end of stroke limit switches to protect the panel from damage due to overtravel in either direction.
Panels can require up to 9000 N of force to move in windy conditions, which both actuators and screw jacks can deliver with ease.
Multiple mounting options are available.
Actuators and screw jacks require little to no maintenance, making them ideal for solar panel applications.
Customization:
Thomson has a long history of building custom products. A custom tailored solution can be an integrated part of the structure and make assembly quick and easy.
Wind, rain, sun and snow:
The elements can put stress on a solar panel. Thomson actuators and screw jacks are built to handle these conditions with little or no service or maintenance.
Limit the movement:
Both actuators and screw jacks can be supplied with built-in adjustable end of stroke limit switches which makes it easy to set the limits of movement.
Feedback:
Thomson actuators and screw jacks are offered with both analog and digital feedback to allow precise tracking of the sun.
solar tracking machine screw jack actuators accurate positioning solar panel tracking system features:
1. Load capacities 5 Ton, 10 Ton, 20 Ton.
2. Travels 750mm, 1200mm, 2000mm etc. Custom length is available.
3. Translating screw with clevis end. Or Keyed screw with threaded end attaches rod end.
4. 24V DC motor with planetary gearheads or AC helical gear reducer are available.
5. Direct-type mounting by motor flanges between jacks and motor/reducer.
6. Accessories: motor flange, bellows boot, protective tube, female clevis end etc.
Tracking the movement of the sun will boost the efficiency and increase output from a given panel by up to 30%. Accurate, trouble-free positioning of the panels is the challenge. The system must be highly rugged and able to withstand wind and weather. It must function reliably and maintenance-free for many years. Thomson linear actuators and screw jacks offer affordable, custom-fitted solutions to these challenges.
Solar tracking requires actuation solutions which are stiff and will not back-drive in high wind conditions. All Thomson actuators and screw jacks can be equipped with a holding brake that eliminates back-driving.
Accurate tracking often requires some form of feedback. Most Thomson actuators and screw jack models can be equipped with encoders, resolvers or potentiometers to meet either analog or digital feedback requirements.
All Thomson actuators and screw jacks are available with adjustable end of stroke limit switches to protect the panel from damage due to overtravel in either direction.
Panels can require up to 9000 N of force to move in windy conditions, which both actuators and screw jacks can deliver with ease.
Multiple mounting options are available.
Actuators and screw jacks require little to no maintenance, making them ideal for solar panel applications.
Customization:
Thomson has a long history of building custom products. A custom tailored solution can be an integrated part of the structure and make assembly quick and easy.
Wind, rain, sun and snow:
The elements can put stress on a solar panel. Thomson actuators and screw jacks are built to handle these conditions with little or no service or maintenance.
Limit the movement:
Both actuators and screw jacks can be supplied with built-in adjustable end of stroke limit switches which makes it easy to set the limits of movement.
Feedback:
Thomson actuators and screw jacks are offered with both analog and digital feedback to allow precise tracking of the sun.
solar tracking machine screw jack actuators accurate positioning solar panel tracking system features:
1. Load capacities 5 Ton, 10 Ton, 20 Ton.
2. Travels 750mm, 1200mm, 2000mm etc. Custom length is available.
3. Translating screw with clevis end. Or Keyed screw with threaded end attaches rod end.
4. 24V DC motor with planetary gearheads or AC helical gear reducer are available.
5. Direct-type mounting by motor flanges between jacks and motor/reducer.
6. Accessories: motor flange, bellows boot, protective tube, female clevis end etc.
