If you have new machines or potential projects and would like to learn more information and price about high quality
SWL1, SWL2.5, SWL5, SWL10, SWL20, SWL25, SWL35, SWL50 and SWL100 screw jacks, contact us today with your requirements. Our teams are looking forward to working with you.
Important Note: most of our standard products with stock components, in other words, in stock and fast delivery.
The high-reliability and synchronisation of a screw jack makes them ideally suited to a wide variety of uses that alternative methods of handling cannot achieve. They can also be used as an alternative to conventional pneumatic and hydraulic systems and are well suited to industry sectors including Steel works equipment, Water processing, Pharmaceutical, Medical & Laboratory equipment, Packaging equipment, Nuclear & Aerospace, and General mechanical handling.
SWL5 Screw Jack Features
1. load capacity 5 ton
2. lift screw diameter 40mm
3. lift screw pitch 7mm
4. gear ratio 6:1, 24:1
5. max.2000mm travel stroke
6. manual or electric drive
SWL5 Screw Jack Dimensions
SWL5 Screw Jack Specifications* Note: The dark gray figures in the tables indicates operational restrictions due to thermal limits. Static only (dynamic not permitted). Selection of screw jacks using these figures should only be carried out in consultation with our engineers. When your selection is made within the areas dark gray, you will need to reduce duty cycle or choose larger model screw jacks in order to allow effective heat dissipation.* Conditions: Duty cycle 20%/h or 30%/10min, 20 °C ambient temperature. * Gear Ratios: H: high ratio, L: slow ratio.* Nm: Input torque required, kW: Input power required.
