THE NAME:

synchronized jack systems

Model: synchronized jack systems
Place of Origin: Made In China
Brand Name: JACTON
Download:
Description:


synchronized jack systems Introduction

synchronized jack systems structures include miter gearboxes, screw jacks, electric motor or gear reducer, hand wheel, pillow block bearings, jaw couplings and line shaftings. We can provide a complete set synchronized jack systems following clients' requirements. Compared to fast speed hydraulic lifting system and pneumatic lifting system, synchronized jack systems is not only for the simple load-supporting from several kilograms to heavy duty several hundreds tons, but also have many advantages such as self-locking without brake or locking mechanism, precisely positioning, full synchronization, manual operated or electric motor driven, quiet environment, easy installation and operation, maintenance free.

synchronized jack systems Efficiency
1. Two synchronized jack systems, includes I, L, T, TI layout configuration, transmission efficiency 95%.
2. Three synchronized jack systems, includes I, L, T, TL, TI, TT layout configuration, transmission efficiency 90%.
3. Four synchronized jack systems, includes U, H, HI, UI, T, TT layout configuration, transmission efficiency 85%.
4. Six synchronized jack systems, includes U, H, HH layout configuration, transmission efficiency 80%.
5. Eight synchronized jack systems, includes H, HH layout configuration, transmission efficiency 80%.
Notes: don't ignore miter gearbox efficiency 98%.

synchronized jack systems Example Pictures






synchronized jack systems Application
synchronized jack systems is used in theatre stage lifts, sheet steel and steel pipes production lines, coil sheet slitter lines, paint coating lines, rewinding lines, pickling lines, cut to length lines, continuous hot dip galvanizing lines, spray infeed conveyor lift systems, wood working machines, plastics processing machines, textile machines, assembly equipment in the automobile and aircraft industries, food and beverage production equipments, packaging machines, adjusting synchronous coil feed lines rolls, feeder levelers and railway maintenance lifting platform etc. Note: several independent motorized screw jacks together constitute a synchronized jack systems, considering full synchronization, if power source is three phase asynchronous motor, must be controlled with PLC (Programmable Logic Controller), or use servo motor screw jacks.
