JTPH170 hollow shaft gearbox right-angle

Model: JTPH170
Categories: Hollow Shaft Gearbox »
Place of Origin: Made In China
Brand Name: JACTON

JTPH170 hollow shaft gearbox right-angle Pictures

JTPH170 hollow shaft gearbox right-angle Descriptions
1. Solid input shaft, hollow output shafts.
2. Maximum allowable hollow shaft diameter 38mm, custom made hollow shafts with smaller sizes.
3. Cubic housing, 170x170x170mm, with all-round tapped holes for universal mounting, 6 possible universal mounting positions, can be easily mounted in any direction.
4. Standard bevel gear ratios 1:1 and 2:1, custom made 1.5:1, 3:1, 4:1 and 5:1 reduction ratios.
5. Drive shafts arrangements available 2-way, 3-way, and 4-way.
6. Drive shafts can be rotated in both clockwise and counter-clockwise rotation direction.
7. Mounting positions available in horizontal mount, over hung mount and wall mount.
8. Maximum allowable torque 290.3 N.m
9. Maximum allowable power 39.2 kw.
10. Maximum allowable speed 1450 rpm.

JTPH170 hollow shaft gearbox right-angle Specifications

JTPH170 hollow shaft gearbox right-angle Dimensions
1. Standard solid input shaft diameter 40mm, custom made smaller or larger sizes input shafts.
2. Non-standard output hollow shafts sizes, maximum allowable output hollow shaft diameter 38mm, custom made hollow shafts with smaller sizes.
