Motorized acme screw jack 2500kg capacity

Motorized screw jack driven motor types include electric motor, gear motor, gear reducer, hydraulic motor, pneumatic motor, explosion proof motor, servo motor and stepper motor. Motor means asynchronous induction motor and above motor no brake, if need, marked in purchase order and invoice.

1. Load capacity 2500 kg
2. Worm screw diameter 30mm
3. Worm screw pitch 6mm
4. Worm gear ratio 24:1
5. Self-locking machine screw, stroke 600 mm
6. 0.37kW DC 12V worm gear motor reducer
7. Upright installation
8. Translating screw design
9. Standard with 1-start lifting screw
10. Lifting Screw Ends: top plate
11. Housing(Gearbox): Ductile Iron
12. Lifting Screw: Carbon steel #45
13. Worm(Input Shaft): Hardened worm, carbon steel #45
14. Worm Gear(Wheel): High strength bronze
15. Accessories: protection tube, motor flange, worm gear reducer, dc 12v motor.



If you have new machines or projects and would like to learn more information and price about high quality motorized acme screw jack, contact us today with your requirements. Our teams are looking forward to working with you. Important Note: most of our standard parts of 12v dc motor screw jack with stock components, in other words, in stock and fast delivery.
