Electro Mechanical Screw Jack Linear Actuator Rising spindle type. The screw jack makes it possible to transform the rotary motion provided by an electric, pneumatic, or hydraulic motor or even a handwheel, into linear motion that allows push or pull vertical lifting and horizontal positioning.
1. Load capacity 10 tons
2. Worm screw dia. 58mm
3. Worm screw pitch 12mm
4. Worm gear ratio 32:1
5. Self-locking acme screw, stroke 75 mm
6. 0.75KW worm gear motor
7. Inverted mount
8. Translating screw design
9. Standard with 1-start lifting screw
10. Lifting Screw Ends: plain end
11. Housing(Gearbox): Ductile Iron
12.Lifting Screw: Carbon steel #45
13. Worm(Input Shaft): Hardened worm, carbon steel #45
14. Worm Gear(Wheel): High strength bronze
15. Accessories: motor flange, worm gear reducer, limit switch and potentiometer
