Motor driven linear screw lift mechanism. Motorised screw jack allowable voltage,phases and hertz includes 380V-3 Phases-50HZ, 220V-3 Phases-50HZ, 400V-3 Phases-50HZ, 415V-3 Phases-50HZ, 440V-3 Phases-50HZ, 480V-3 Phases-50HZ, 220V-3 Phases-60HZ, 240V-3 Phases-60HZ, 480V-3 Phases-60HZ, 110V-Single Phase-60HZ, 120V-Single Phase-60HZ, 220V-Single Phase-50HZ, 230V-Single Phase-50HZ, 240V-Single Phase-50HZ. For special application, for example solar tracker industry, most of engineers or designers prefer to use 24V, 36V, 48V DC motor with gear reducer direct connected worm gear screw jack.
1. Load capacity 3 ton
2. Lifting screw dia. 32mm
3. Lifting screw pitch 6mm
4. Worm gear ratio 24:1
5. Self-locking acme screw, stroke 300 mm
6. 0.75kw 3-phase motor
7. Upright mount
8. Translating screw design
9. Standard with 1-start lifting screw
10. Lifting Screw Ends: Clevis end
11. Housing(Gearbox): Ductile Iron
12.Lifting Screw: Carbon steel #45
13. Worm(Input Shaft): Hardened worm, carbon steel #45
14. Worm Gear(Wheel): High strength bronze
15. Accessories: motor flange, ac motor
